AC1200W Horizontal Drive Wheel

Specifications
Model Voltage/Freq Power Speed Reduction Ratio Max Wheel Load
G032AQ1A162 16V/100Hz  1200W 2850RPM 31.42 1000Kg
Wheel Torque Load Current Drive Speed Electrical Brake Field Weight
220N-m 65A 4.2Km/h 8N-m AC Induction 32Kg
