DC500W Aerial Work Drive Wheel

Specifications
Model Voltage Power Speed Reduction Ratio Max Wheel Load
G0291AE5D241 24V 500W 2800RPM 29 500Kg
Wheel Torque Load Current Drive Speed Electrical Brake Wheel Diameter Weight
50N-m 25A 4.2km/hr 4N-m Ø 230mm 22Kg
